CASTOTIG® 1611 ADVANCE DC WELDING EQUIPMENT

In stock
EXCEPTIONALLY COMPACT AND PORTABLE TIG – MMA WELDING MACHINE.
CastoTIG 1611 DC ADVANCE is an advancement of proven Castolin Eutectic inverter technology. The microprocessor controlled, compact power source is specially designed for TIG welding with direct current and is also useful for Manual Metal Arc Electrode applications.

Description

  • Minimal size and weight, low energy consumption and generator-usability.
  • Easy-to-use by menu guides and simple touch-panel.
  • Clear readable digital-display for programming and status.
  • The electronic high-frequency-ignition ensures perfect, contact-free ignition on all applications.
  • Lift-Arc-ignition for welding in areas with sensitive electronics, e.g. control and steering systems.
  • Standard-integrated pulse function for improved welding pool control especially on thin sheets.
  • All parameters for professional TIG-welding are directly accessible. 2 and 4 step modes.
  • Auto-Pulse for simplified adjustment during pulse welding. Set only the current, all pulse parameters follow automatically.
  • Improved spot function for perfect stapling.
  • Now also remote controllable. Up/down function from the torch with all up/down torches using the adapter set.

Technical Data

Current Range
5 – 160 A
Mains Voltage
1 x 230 V / 50/60 Hz
Open Circuit Voltage MMA
54 V
Open Circuit Voltage TIG
10V
Mains fuse (slow-blow)
16 A
Mains power at 100% DC – TIG
2,5 kVA
Protection class
IP 23S
Official Approvals
CE, S
Weight with mains cable
6,6 kg
Dimensions (mm)
360 (L) x 120 (B) x 215 (H)
